| Parameters |
Camera
Image Sensor, 1/2.9" Progressive Scan CMOS
Max. Resolution, 1920 × 1080
Shutter Time, 1/3 s to 1/100,000 s
Min. Illumination, Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
Day & Night, IR cut filter
Angle Adjustment, Pan: 0° to 355°,tilt: 0° to 75°
Lens
Lens Type, Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV, 2.8 mm, horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°
4 mm, horizontal FOV 80°, vertical FOV 44°, diagonal FOV 94°
Lens Mount, M12
Iris Type, Fixed
Aperture, F2.2
Depth of Field, 2.8 mm: 0.8 m to ∞
4 mm: 1 m to ∞
DORI
DORI, 2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m
4 mm, D: 55 m, O: 22 m, R: 11 m, I: 5 m
Illuminator
Supplement Light Type, IR
Supplement Light Range, Up to 20 m
Smart Supplement Light, Yes
IR Wavelength, 850 nm
Video
Main Stream, 50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream, 50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Video Compression, Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264
Video Bit Rate, 32 Kbps to 8 Mbps
H.264 Type, Baseline Profile,Main Profile,High Profile
H.265 Type, Main Profile
Bit Rate Control, CBR,VBR
Network
Security, Password protection, complicated password, watermark, basic and digest authentication for HTTP, security audit log, host authentication (MAC address)
Simultaneous Live View, Up to 6 channels
API, ISAPI,SDK
Protocols, TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, UDP, QoS
User/Host, Up to 32 users
3 user levels: administrator, operator, and user
Client, iVMS-4200
Web Browser, Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Wide Dynamic Range (WDR), Digital WDR
SNR, ≥ 52 dB
Day/Night Switch, Day,Night,Auto,Schedule
Image Enhancement, BLC,HLC,3D DNR
Image Settings, Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Interface
Ethernet Interface, 1 RJ45 10 M/100 M self-adaptive Ethernet port
Event
Basic Event, Motion detection,exception
Linkage, Notify surveillance center
General
Power, 12 VDC ± 25%, 0.4 A, max. 4.8 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 6.5 W
Material, Plastic
Dimension, Ø110.8 mm × 85.2 mm (Ø4.36" × 3.35")
Package Dimension, 163 mm × 75 mm × 75 mm (6.4" × 3.0" × 3.0")
Weight, Approx. 240 g (0.5 lb.)
With Package Weight, Approx. 380 g (0.8 lb.)
Storage Conditions, -10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions, -10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
Language, English, Ukrainian
General Function, Heartbeat,mirror,password protection,password reset via email
Approval
EMC, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
Safety, CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
Environment, CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
|
